UPS LX SERIES (15K-40K)

LECXO UPS Series (2kVA – 3kVA) – Key Specifications

Models & Capacity:

• LX2KTON: 2000 VA / 1800 W

• LX3KTON: 3000 VA / 2700 W

Input: 208–240 V AC | Operating Range 110–300 V | Power Factor ≥ 0.99 | Bypass Frequency 40–70 Hz (Auto-sensing)

Output: 208–240 V AC | Pure Sine Wave | Voltage Regulation ±1% | Power Factor 0.9 | THDv ≤3% (Linear Load) | Crest Factor 3:1

Transfer Time: AC → Battery: 0 ms | Inverter → Bypass: 4 ms (Typical)

Efficiency:

• LX2KTON: AC Mode 91% | ECO Mode 96%

• LX3KTON: AC Mode 92% | ECO Mode 97%

Battery: VRLA Lead-Acid Maintenance-Free |

• LX2KTON: 48 V, 4 batteries

• LX3KTON: 72 V, 6 batteries | Typical Recharge 4 h | Max Charging Current 1 A

Management: LED + LCD Display | Monitors Voltage, Frequency, Load %, Battery, Backup Time, Temperature, Faults

Environment: Operating Temp 0–40°C | Humidity 20–95% | Noise <50 dB | Altitude <1000 m

Physical:

• LX2KTON: 191 × 460 × 337 mm | 19.5 kg

• LX3KTON: 191 × 460 × 337 mm | 24.5–29.5 kg

Compliance: IEC/EN 62040-1, 62477-1 (Safety) | IEC/EN 62040-2, IEC 61000 series (EMC) | IEC 62040-3:2021 (Performance)

Highlights:

• Pure Sine Wave Output

• Smart Battery Management with VRLA Maintenance-Free Batteries

• Fast Transfer Time (0–4 ms)

• High Efficiency (ECO Mode up to 97%)

• LED & LCD Monitoring for Real-Time Status
